Securing a gun safe to a wall or floor isn't optional in Ireland — it's part of what a Garda inspecting officer checks before issuing or renewing a Firearms Certificate, and an unsecured safe is a fail on the spot. This guide covers the bolts, anchors and fixing method that pass inspection and actually stop a safe being carried out the door.
- Bolt through the safe's pre-drilled fixing points into masonry or timber studs, never into plasterboard alone.
- Use M8 or M10 expansion anchors for concrete floors and 100mm coach screws for timber joists in 2026 installs.
- A gun safe under 200kg that isn't bolted down fails a Garda inspection regardless of its rating.
- Cogswell & Harrison and similar 4-gun cabinets ship with fixing bolts included — check before buying extras.
- Floor fixing beats wall fixing on stud walls; concrete floor or slab fixing is the safest option for most Irish homes.
Why this matters
A gun safe that sits unbolted on a floor is a box, not a safe. Under Irish firearms law, secure storage means the safe is fixed to the structure of the building — a Garda Superintendent's inspection will look for this specifically before granting or renewing a Firearms Certificate in 2026, and a safe you can rock or tip fails that check even if it's rated to hold six rifles.
Most Irish homes give you two fixing options: a solid floor (concrete slab, tiled screed) or a masonry wall. Timber-framed stud walls and plasterboard are not valid fixing points on their own — you need to go through them into the stud or the concrete behind.
What you'll need
- The gun safe itself, positioned in its final location before fixing (most weigh 40kg to 90kg empty — get help moving it)
- A cordless drill with masonry and metal bits sized to the safe's pre-drilled fixing holes
- Expansion anchors or resin anchors (M8 or M10) for concrete/masonry, or coach screws for timber joists
- A spirit level or laser level
- A vacuum or brush for drilling dust
- Torque wrench or socket set (optional but recommended for consistent tightening)
- Safety glasses and a dust mask
Many gun storage cabinets, including the standard 4 and 6-gun models sold in Ireland, come with fixing bolts pre-included in the box. Check the spec sheet before you order separate anchors — buying duplicates is a common and avoidable cost.
The steps
1. Choose the fixing surface
Decide between floor and wall before you drill anything. Floor fixing into a solid concrete slab is the strongest option and works for safes of any weight. Wall fixing only works into solid masonry (block or brick) — never into a stud partition wall unless you're bolting through to a structural stud with a backing plate.
2. Position the safe and mark the holes
Set the safe exactly where it will live, level it with a spirit level, and open the door to access the internal fixing points. Most cabinets have 2 to 4 pre-drilled holes in the base or rear panel. Mark through these onto the floor or wall with a pencil or masking tape.
3. Drill the anchor holes
Move the safe aside slightly and drill into the marked points using a masonry bit matched to your anchor size — typically 10mm for M8 anchors, 12mm for M10. Drill to the depth specified on the anchor packaging, usually 60mm to 80mm into solid concrete. Clear dust from each hole before inserting the anchor; leftover dust weakens the grip significantly.
4. Insert the anchors
Tap the expansion anchors into the drilled holes until flush. For timber floor joists, skip the anchor and go straight to a pilot hole for the coach screw — a 5mm pilot bit for a 10mm coach screw is standard. Resin anchors need curing time before load; check the tube for the exact window, usually 20 to 60 minutes at room temperature.
5. Reposition and bolt through
Slide the safe back over the anchors, align the fixing holes, and drop the bolts through into the anchors. Hand-tighten first to confirm alignment across all fixing points before applying full torque.
6. Torque to spec
Tighten each bolt fully with a socket or torque wrench. Over-tightening on a thin-gauge safe body can distort the base plate, so go firm and even across all points rather than cranking one bolt to maximum. A safe with 4 fixing points should feel immovable when you push against the top corner — if it rocks even slightly, one bolt hasn't seated.
7. Test the fixing
Push and pull the top of the safe from multiple directions. It should not shift, tilt, or lift at any corner. This is the same test a Garda inspecting officer will apply, so do it yourself before the visit rather than finding out on the day.
Common mistake: fixing into plasterboard-clad stud walls without locating and bolting through to the stud itself. A safe bolted only into plasterboard will pull straight out of the wall with moderate force — this fails inspection and defeats the point of the safe entirely.
Troubleshooting
- Anchor spins without gripping — the hole is oversized or the masonry is too soft (common in old lime mortar). Switch to a resin anchor, which grips through chemical bond rather than expansion friction.
- Safe rocks on one corner after fixing — the floor isn't level. Use washers as shims under the low corner rather than over-tightening the opposite bolts.
- Can't locate the stud behind plasterboard — use a stud finder or drill a small pilot hole and check with a wire coat hanger before committing to the fixing position.
- Coach screw won't bite into old timber joists — pre-drill a slightly larger pilot hole and use a longer screw; old dried timber splits rather than grips with undersized pilots.
- Safe fixing bolts supplied are too short for a thick tiled floor — buy longer anchors separately rather than forcing the standard ones; undersized anchor depth is a frequent inspection fail.
- Drill won't penetrate concrete floor — you likely need a hammer drill or SDS drill rather than a standard combi drill for dense slab concrete.
Tools and resources
- Cordless drill with masonry bit set
- M8/M10 expansion or resin anchors, or 100mm coach screws for timber
- Torque wrench or socket set
- Spirit level and stud finder
- A gun storage cabinet with pre-drilled fixing points and bolts included, sized to the number of rifles and shotguns you're licensed to hold
What to do next
Once the safe is bolted down, the next thing a Garda inspection checks is what's stored inside and how — ammunition kept separately from firearms, moderators and scopes secured, and the safe itself locked whenever it's not in active use. If you're applying for or renewing a Firearms Certificate in 2026, get the secure storage sorted before you book the inspection, not after.
FAQ
How to secure a gun safe legally in Ireland?
Bolt the safe through its pre-drilled fixing points into a concrete floor or solid masonry wall using M8 or M10 anchors. A Garda inspecting officer checks that the safe cannot be moved or tipped, and this is required for Firearms Certificate approval in 2026.
Do I need to bolt a gun safe to the floor or wall?
Either works if the surface is solid concrete or masonry, and floor fixing is generally the stronger option. Stud walls with plasterboard only pass if you bolt through to the structural stud, not the board alone.
What size anchors do I need for a gun safe?
Most gun cabinets use M8 or M10 expansion anchors for concrete, drilled 60mm to 80mm deep. Timber floors typically take a 10mm coach screw with a 5mm pilot hole.
Can a gun safe be fixed to a timber floor?
Yes, provided you fix into the joist rather than the floorboard alone. Use coach screws long enough to bite into solid joist timber, not just the surface board.
Will a Garda inspection fail an unbolted gun safe?
Yes. An unsecured safe, regardless of its weight or rating, fails a secure storage inspection because it can be carried or tipped out of the property.
Does a heavy gun safe still need bolting down?
Yes. Weight alone doesn't satisfy secure storage requirements — safes up to 90kg have been removed by two people without fixing bolts, so anchoring is mandatory regardless of size.
How many bolts does a gun safe need?
Most cabinets have 2 to 4 pre-drilled fixing points, and all of them should be used. Skipping fixing points leaves a pivot point the safe can rock or lever against.
Do gun safes come with fixing bolts included?
Many do, including standard 4 and 6-gun cabinets sold in Ireland, but always confirm on the product spec before ordering separate anchors.
One last thing
The fixing bolt is the part people skip because it's hidden once the safe is in place — but it's also the first thing checked on a follow-up inspection if there's ever a break-in report in the area. Bolt it once, properly, and you won't be back on your knees with a drill in six months.
